Surveyor Legend 260BHLE

Forest River Travel Trailer

Surveyor Legend 260BHLE Travel Trailer by Forest River

It's never been easier to build the RV of your dreams!

Use the form below to select the equipment & décor that's perfect for you. When you are done, you can get your very own

customized price quote by clicking the "Get The Price" button.

Equipment
Standards
Specifications
  • Factory Standards
    Additional 200 Watt Solar Panel
    Extended Season Ready - 2" Aluminum Framed Floor w/ Block Foam Insulation, Sealed Underbelly w/ Forced Heat & Radiant Foil Insulation, 12V Tank Heaters, Goodyear® Tires, Automotive Style Tinted Front Windshield, 15K A/C, 200 Watt Solar Panel & 30 Amp Solar Controller, Solar Inverter Prep, Tire Pressure Monitoring System (TPMS), Electric Awning w/ LED Lightstrip, Central Vac System,10 Cu. Ft. 12V Black Glass Refrigerator, Adjustable Platform Entry Step w/ Night Light (All Entries), 2" Rear Accessory Hitch, Tankless Water Heater, Roller Shades T/O, Upgraded Slow-Close Shower Door, HD TV, Surf(x)® Seamless Countertops T/O, 21" Oven (N/A Sub 4 Series), 3 Speed Bath Fan, Aluminum Wheels, Slam Latch Exterior Baggage Doors, Outdoor Kitchen, Hot & Cold Exterior Spray Port, Power Tongue Jack w/ Hitch Light, Roof Ladder Prep, Rear Camera Prep
    Interior Decor
    Factory Options
    Includes 2nd A/C Prep

  • APPLIANCES/EQUIPMENT

    • 20,000 BTU Furnace (Sub-4s)
    • 30,000 BTU Ducted Furnace
    • 6 Gallon G/E DSI High Output Quick Recovery Hot Water Heater
    • Digital Thermostat Wall Mounted
    • Greystone® Gourmet Cooking Collection (N/A Sub-4s)
    • Greystone® Convection Microwave (Sub-4s)
    • Range Top 3-Burner and 17” Gas Oven w/LED Lights
    • Range Top Two-Burner (Sub-4s)
    • Stainless Power Range Hood w/Light

    BATH

    • 12V Power Exhaust Fan
    • Heat Duct & A/C Vent (Most Models)
    • Privacy Door Lock
    • Skylight over Tub/Shower
    • Linen Storage Cubbies (Select Models)
    • Systems Monitor Panel
    • Porcelain Toilet
    • Vented Windows (Select Models)

    BEDROOM

    • 60 X 80 Residential Queen Bed
    • Bedding Embossed Coverlet
    • Cubbie Storage Area w/110V Outlets & Cup Holders
    • Double-Strut Lift Super Storage Under Bed (Most Models)
    • Drawer(s) On Each Side Of Bed
    • Indura-Kleen Evergreen Mattress (Antibacterial, Hypoallergenic, Mold & Mildew Resistant)
    • Oversize Wardrobes -Actually Fit Hangers & Clothes
    • Teddy Bear® Bunk Bedding (Bunk Bed Models)

    CONSTRUCTION

    • 1 1/2” Laminated Aluminum Frame Sidewalls, Rear Wall, & Slideout Walls (R7 Closed Cell Block Foam Insulation)
    • 2” Laminated Aluminum Perimeter Floor & Studs (R9 Closed Cell Block Foam Insulation)
    • Aluminum Framing All Openings; Windows, Doors, Appliances
    • Roof: Trusses 16? On-Center, R14 Insulation, 3/8? Decking
    • Underbelly: Lami-Plast™ All Weather Protection Fully Heated & Enclosed

    ELECTRICAL

    • 30 AMP Marine Grade Detachable Power Cord
    • 55 AMP Converter w/Charger (35 AMP Sub-4s)
    • Battery Disconnect Mounted Front A-Frame
    • Cable & Satellite Ready
    • GFI 120V Exterior Receptacle Doorside
    • LED Amber Patio Light
    • LED Interior/Exterior Lighting

    EXTERIOR

    • Two Tone Diamond Ice & White Star Gel-Coated Fiberglass
    • Front Diamond Plate Protection
    • Dual Battery Rack
    • 4” Square Bumper w/Sewer Hose Storage
    • Magnetic Baggage Door Catches

    INTERIOR

    • 82” Ceiling Height (78” Sub-4s)
    • A/C Ceiling Vents Adjustable Flow & Direction
    • Adjustable Shelves in Pantry (Where Applicable)
    • Ceiling Light Switch At Entrance Door
    • Congoleum Designer Carefree Linoleum
    • Strut Assisted, EZ Access Dinette Storage
    • Long Lasting Wood Drawers w/Ball Bearing Glides
    • Modern Frame Edge Cabinets w/Prism Curio Glass On Overheads
    • Shaw® Stain & Soil Resistant Carpet (Slide-Outs)
    • Vented Side Windows In Slide-Outs

    PLUMBING

    • 12V Demand Water Pump
    • Black Tank Flush *Artisan Package
    • City Water Fill
    • Color Coded Water Lines
    • Gravity Water Fill
    • Rotocast Fresh Water, Black, Gray Tanks (Underfloor)
    • Water Heater Bypass Kit
    • Winterization Kit

    RUNNING GEAR

    • 2 5/16” Coupler
    • 205/75R15 LRD (Select Models)
    • 225/75R15 LRD (Sub-4s & Select Models)
    • Automotive Style Wheels
    • Lippert Axles Leaf Spring Suspension
    • Nitrogen Filled Radial Tires w/Steel Lug Inserts
    • Self Adjusting Electric Brakes
    • Spare Tire & Carrier
    • Super Lube Hubs

    SAFETY AND SECURITY

    • Brake-Away Switch
    • Carbon Monoxide Detector
    • Dead Bolt Door Lock
    • Fire Extinguisher
    • Ground Fault Electrical Circuit(s)
    • Heavy Duty Safety Chains
    • LP Leak Detector
    • Smoke Detector
    • Tinted Safety Glass Windows
  • Specification Imperial Metric
    Cargo Capacity 1,962 lbs 889.95 kg
    Dry Weight 5,778 lbs 2,620.86 kg
    GVWR 7,740 lbs 3,510.80 kg
    Hitch Weight 740 lbs 335.66 kg
    Overall Length 29' 11" 9.12 m
    Overall Width 96" 243.84 cm
    Black Water Tank 30 gal 113.56 l
    Fresh Water Tank 40 gal 151.42 l
    Gray Water Tank 40 gal 151.42 l
Retail Price $43,645
