It's never been easier to build the RV of your dreams!
Use the form below to select the equipment & décor that's perfect for you. When you are done, you can get your very own
customized price quote by clicking the "Get The Price" button.
<!– 2504 –>
WARRANTY 12 Months/12,000 mile basic limited warranty Chassis warranty (see owners manual)
SYSTEMS Battery disconnect Water heater bypass (1) Deep cycle coach battery Optional (2) Deep cycle coach batteries LED lighting Easy Access battery in step-well 30 Amp service with power cord 60 Amp Progressive Dynamics converter 6 Gallon DSI gas/electric water heater 30,000 BTU furnace Emergency start switch Satellite/cable connection 15,000 BTU ceiling ducted, ultra quiet roof air with heat pump (N/A w/dual AC option) 4.5 KW Gas generator (Ford/Chevy only) Heated, enclosed holding tanks and valves (N/A 2250SLE, 2550DSLE) Arctic Package (12V tank heaters) CO, LP and smoke detector Winegard Air 360+ digital antenna Side-mounted solar prep connection (N/A with roof-mounted solar) Optional 190 Watt roof-mounted solar powered 12V charging system (IPO side-mounted charger prep)
EXTERIOR 2” Aluminum framed laminated sidewalls Superlite composite substrate Gel Coat exterior fiberglass Block foam insulation Power patio awning with LED light strip Slide-out awnings Fiberglass roof One-piece fiberglass front cap Roto-cast storage compartments Aluminum running boards Tinted sliding windows 7,500 Lbs. hitch, 7-pin connector (E450) 5,000 Lbs. hitch, 7-pin connector (Chevy/E350) Integrated entry step Optional Automatic leveling system (4-point) (N/A on Chevy) LP quick connect Black tank flush On-The-Go™ Ladder Bracket (most models)
CAB AREA Power windows and door locks Keyless entry (N/A Chevy) Backup camera/side view cameras with 3-way monitor
KITCHEN Recessed 3-burner range with flush glass cover 1.3 Cu. ft. convection microwave 10.7 Cu. ft. 12V refrigerator Soft touch self-closing drawer guides Cordless 12V charging plate
BATHROOM Electric roof fan Oxygen-infused shower head with flexible extension Shower skylight
BEDROOM Black-out roller shades LIVING ROOM Convertible dinette for additional sleeping capacity Black out roller shades 12V LED flat panel adjustable side TV Child seat head tethers in dinette Maxx Air multi-speed power fan with cover
| Specification | Imperial | Metric |
|---|---|---|
| Cargo Capacity | 2,656 lbs | 1,204.74 kg |
| GAWR (Front) | 5,000 lbs | 2,267.96 kg |
| GAWR (Rear) | 9,600 lbs | 4,354.49 kg |
| GCWR | 22,000 lbs | 9,979.03 kg |
| GVWR | 14,500 lbs | 6,577.09 kg |
| Hitch Rating | 5,000 lbs | 2,267.96 kg |
| Overall Height | 11' 3" | 3.43 m |
| Overall Length | 24' 6" | 7.47 m |
| Overall Width | 101" | 256.54 cm |
| Wheelbase | 158" | 401.32 cm |
| Black Water Tank | 39 gal | 147.63 l |
| Fresh Water Tank | 44 gal | 166.56 l |
| Fuel Capacity | 55 gal | 208.20 l |
| Gray Water Tank | 39 gal | 147.63 l |
